Osprey Talon OG-3G-2D
Dual Channel 1080P60 H.265/H.264 Video Decoder
Product by: Osprey Video
Model: OG-3G-2D SKU: 95-00531 Video Outputs: 2x 3G-SDI (Dual Channel Decoding up to 2x 1080P60) Audio Outputs: Embedded 8Ch for each output (4 stereo pairs) Genlock: Blackburst, Tri-Level I/O Connections: HD-BNC for SDI Ethernet #1 - RJ45 Ethernet #2 - openGear Frame Genlock - openGear Frame Video Formats: PAL 576i, NTSC 480i 720p23.98, 24, 25, 29.97, 30, 50, 59.94, 60 1080i at 30, 25 fps * 1080p23.98, 24, 25, 29.97, 30, 50, 59.94, 60 * interlaced decoding only supported HEVC point-to-point between Talon Encoder and Talon Decoder Color: Up to 10bit 4:2:2 REC 709 Streaming Transports: UDP, RTP, SRT™,Zixi™ Video Processing: none - output matches input stream Video Compression: H.264 (AVC), H.265 (HEVC) Audio Compression: AAC-LC Audio: Input Sample Rate 48kHz Audio Bitrate 64kbps to 512kbps Software Features: Enhanced security features Remote firmware upgrade from web Network time protocol JSON REST API for software integration Password protected SMPTE 2038 support Customizable notice and consent banner Secure HTTPS (SSL) web based management Open VPN Client Whitelist/Firewall for Management IP Access Dual GigE Ethernet: Ethernet Port #1: GigE RJ45 Ethernet Ethernet Port #2: GigE openGear Frame - requires Ross Video MFC-OG3-N Advanced Networking Frame Controller In the Box: Decoder Rear IO Module Mechanical: Density 18 Cards per OG3 or OGx Frame (20 cards when ordered with customized OGx Frame) Compatible with OG-X-FR, OG-3-FR and DFR8321 Frames Operating Temperature -20C to 60C Power 12V | 13W max
